• Wide race and rollers and steel cage for high dynamic load ratings
• Race-mounted felt seal with flinger and misalignment sealing
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy cast iron housing

Dimensions

Bore Diameter (in)	3.1875 in
Overall Length (in)	10.44 in
Overall Width (in)	4.47 in
Overall Height (in)	7.63 in
Slot Width (in)	1.81 in
Adjustment Slot Width (in)	1.81 in
Adjusting Screw Clearance Hole Diameter (in)	1.81 in
Adjusting Screw Square Nut Seat Height (in)	2.88 in
Adjustment Pad Height (in)	4.88 in
Slot Spacing (in)	6.81 in
Locking Collar Outside Diameter (in)	5.31 in
Housing Outside Diameter to Cast Square Nut Slot Face (in)	7.63 in
Centerline to Outermost Bearing Face (in)	2.66 in
Length Through Bore (in)	4.47 in

Technical Specifications

Maximum Speed (RPM)	2500 rpm
Seal Type	Felt Labyrinth Seal
Measure Units	Inch
Rolling Element	Spherical Roller
Radial Dynamic Load Capacity (lb)	72,640 lb
Frame Type	Center Pull Wide Slot
Housing Construction	Solid
Bore Shape	Straight
Platform	USRB
Misalignment Type	Dynamic
Housing Color	Gray
Outer Ring Land Profile	Standard
End Cap	No
Series	USTU5000
Lubrication Method	Lubrication Fitting
Static Load Rating (lb)	105,628 lb
Component Description	Take Up Bearing Only
Radial Clearance	Standard
Housing Type	Take Up, Wide Slot
Shaft Locking Type	Single Set Collar
Fixed/Expansion	Fixed
Housing Style	Take-Up Block
Housing Material	Cast Iron
Cage Material	Steel
Ability to Relubricate	Yes
Grease Fitting Thread Size	1/8 NPT
Bearing Insert Finish	Black Oxide Coated
Lubricant	Lithium Complex NLGI 2 Grease
Insert	USI5000-303
Misalignment Capability	±2.0° Misalignment - Dynamic
Size Code	10
Bearing Insert Material	52100 Bearing Steel, Black Oxided

General Specifications

UPC	662461367001
Weight	40.93 LB
Packaged Length	10.70 IN
Packaged Width	7.63 IN
Packaged Height	5.00 IN
HTC	8483.20.4080
Country of Origin	United States of America
