• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Single lip contact seal with black oxide bearing races
• Metric fitting and mounting bolts
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	3.22 in
Bolt Size (in)	3/8 in
Overall Height (in)	1.74 in
Overall Length (in)	5.38 in
Bolt Size (mm)	M10 mm
Bore Diameter (mm)	30 mm
Base to Center Height (in)	3.75 in
Foot Height (in)	0.38 in
Length Through Bore (in)	1.61 in
Bolt Spacing (in)	1.8750 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Bracket, Three Bolt
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Locking Collar Outside Diameter (in)	2.23 in
Inner Race Heat Treat Method	Zone-Hardened
End Cap Available	No
Bearing Type	Standard Duty
Insert	5206TMC
Maximum Speed (RPM)	5450 rpm
Bearing Insert Material	52100 Bearing Steel
Static Load Rating (lb)	2,567 lb
Dynamic Load Rating (lb)	4,381 lb
Bolt Spacing Height Direction (in)	1.25 in
Vibration Frequency Outer Ring Defect	0.0595 cps
Shaft Locking Type	Concentric
Size Code	2-13
Bearing Centerline to Bolt Hole Center (in)	2.0625 in
Vibration Frequency Fundamental Train	0.0066 cps
Cage Type	Land Riding Retainer
Housing Material	Cast Iron
Vibration Frequency Inner Ring Defect	0.0905 cps
Bearing Insert Finish	Black Oxide
Misalignment Capability	±2.0° Misalignment - Static Only
Lubricant	Lithium Complex NLGI 2 Grease
Max Operating Temperature (F)	220 °F
Radial Clearance	Standard
Fixed vs. Expansion	Fixed
Housing Coating	Powder Coated
Inner Ring Outside Diameter (in)	1.594 in
Vibration Frequency Roller Spin	0.0385 cps
Grease Fitting Thread Size	1/4-28
Housing Width (in)	3.22 in

General Specifications

UPC	662461254318
Weight	3.20 LB
Packaged Length	1.69 IN
Packaged Width	3.50 IN
Packaged Height	5.75 IN
HTC	8483.20.4040
Country of Origin	United States of America
