• Wide race and rollers and steel cage for high dynamic load ratings
• Race-mounted felt seal with flinger and misalignment sealing
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy cast iron housing

Dimensions

Bore Diameter (in)	2.4375 in
Overall Height (in)	5.88 in
Overall Width (in)	3.37 in
Overall Length (in)	7.94 in
Base to Center Height (in)	4.938 in
Slot Width (in)	1.06 in
Slot Length (in)	4.75 in
Adjustment Pad Height (in)	3.75 in
Adjustment Slot Width (in)	1.31 in
Adjusting Screw Square Nut Seat Height (in)	2.25 in
Slot Spacing (in)	5.13 in
Adjusting Screw Clearance Hole Diameter (in)	1.31 in
Locking Collar Outside Diameter (in)	4 in
Length Through Bore (in)	3.37 in
Centerline to Outermost Bearing Face (in)	1.95 in
Housing Outside Diameter to Cast Square Nut Slot Face (in)	5.75 in

Technical Specifications

Seal Type	Felt Labyrinth Seal
Rolling Element	Spherical Roller
Measure Units	Inch
Maximum Speed (RPM)	3250 rpm
Frame Type	Center Pull Wide Slot
Radial Dynamic Load Capacity (lb)	44,691 lb
Bore Shape	Straight
Housing Construction	Solid
Housing Color	Gray
Platform	USRB
Outer Ring Land Profile	Standard
End Cap	No
Misalignment Type	Dynamic
Series	USTU5000
Lubrication Method	Lubrication Fitting
Static Load Rating (lb)	59,535 lb
Component Description	Take Up Bearing Only
Fixed/Expansion	Fixed
Shaft Locking Type	Single Set Collar
Cage Material	Steel
Housing Type	Take Up, Wide Slot
Housing Style	Take-Up Block
Radial Clearance	Standard
Housing Material	Cast Iron
Ability to Relubricate	Yes
Bearing Insert Material	52100 Bearing Steel, Black Oxided
Insert	USI5000-207
Grease Fitting Thread Size	1/8 NPT
Bearing Insert Finish	Black Oxide Coated
Size Code	8
Lubricant	Lithium Complex NLGI 2 Grease
Misalignment Capability	±2.0° Misalignment - Dynamic

General Specifications

UPC	662461366493
Weight	17.67 LB
Packaged Length	8.44 IN
Packaged Width	5.94 IN
Packaged Height	4.06 IN
HTC	8483.20.4080
Country of Origin	United States of America
