• Wide race and rollers and steel cage for high dynamic load ratings
• Race-mounted double-lip contact seal with flinger and misalignment sealing
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy 4-bolt cast iron housing

Dimensions

Bolt Size (in)	5/8 in
Bore Diameter (in)	2.9375 in
Foot Height (in)	2.25 in
Base to Center Height (in)	3.25 in
Overall Length (in)	10.44 in
Overall Width (in)	3.88 in
Overall Height (in)	6.44 in
Base Width (in)	3.75 in
Locking Collar Outside Diameter (in)	4.52 in
Bolt Spacing Max (in)	8.38 in
Bolt Spacing (in)	8.13 in
Length Through Bore (in)	3.88 in
Centerline to Outermost Bearing Face (in)	2.42 in
Bolt Spacing Min (in)	7.88 in

Technical Specifications

Maximum Speed (RPM)	1600 rpm
Seal Type	Multi-Lip Contact Seal
Rolling Element	Spherical Roller
Measure Units	Inch
Housing Construction	Solid
Radial Dynamic Load Capacity (lb)	47,447 lb
Bore Shape	Straight
Misalignment Type	Dynamic
Housing Color	Gray
End Cap	No
Outer Ring Land Profile	Standard
Platform	USRB
Series	USRBF5000
Lubrication Method	Lubrication Fitting
Static Load Rating (lb)	65,610 lb
Radial Clearance	Standard
Cage Material	Steel
Shaft Locking Type	Single Set Collar
Fixed/Expansion	Fixed
Housing Type	Pillow Block, Four Bolt
Housing Style	Pillow Block
Housing Material	Cast Iron
Ability to Relubricate	Yes
Grease Fitting Thread Size	1/8 NPT
Size Code	9
Misalignment Capability	±2.0° Misalignment - Dynamic
Bearing Insert Finish	Black Oxide Coated
Insert	USI5000-215-C
Lubricant	Lithium Complex NLGI 2 Grease
Bearing Insert Material	52100 Bearing Steel, Black Oxided

General Specifications

UPC	662461363522
Weight	26.57 LB
Packaged Length	10.70 IN
Packaged Width	7.63 IN
Packaged Height	5.00 IN
HTC	8483.20.8080
Country of Origin	Mexico
