• Wide race and rollers and steel cage for high dynamic load ratings
• Race-mounted double-lip contact seal with flinger and misalignment sealing
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy 2-bolt cast iron housing

Dimensions

Bolt Size (in)	3/4 in
Bore Diameter (in)	2.9375 in
Overall Height (in)	6.44 in
Foot Height (in)	2.25 in
Overall Length (in)	10.44 in
Base Width (in)	2.81 in
Base to Center Height (in)	3.25 in
Overall Width (in)	3.69 in
Locking Collar Outside Diameter (in)	4.52 in
Bolt Spacing (in)	8.13 in
Length Through Bore (in)	3.69 in
Centerline to Outermost Bearing Face (in)	2.36 in
Bolt Spacing Min (in)	7.81 in
Bolt Spacing Max (in)	8.44 in

Technical Specifications

Measure Units	Inch
Maximum Speed (RPM)	1600 rpm
Seal Type	Multi-Lip Contact Seal
Rolling Element	Spherical Roller
Bore Shape	Straight
Housing Construction	Solid
Radial Dynamic Load Capacity (lb)	47,447 lb
Housing Color	Gray
Misalignment Type	Dynamic
Platform	USRB
End Cap	No
Outer Ring Land Profile	Standard
Series	USRB5000
Lubrication Method	Lubrication Fitting
Static Load Rating (lb)	65,610 lb
Shaft Locking Type	Single Set Collar
Cage Material	Steel
Housing Style	Pillow Block
Fixed/Expansion	Fixed
Housing Material	Cast Iron
Radial Clearance	Standard
Housing Type	Pillow Block, Two Bolt
Ability to Relubricate	Yes
Bearing Insert Finish	Black Oxide Coated
Lubricant	Lithium Complex NLGI 2 Grease
Misalignment Capability	±2.0° Misalignment - Dynamic
Grease Fitting Thread Size	1/8 NPT
Size Code	9
Insert	USI5000-215-C
Bearing Insert Material	52100 Bearing Steel, Black Oxided

General Specifications

UPC	662461357200
Weight	23.58 LB
Packaged Length	10.70 IN
Packaged Width	7.63 IN
Packaged Height	5.00 IN
HTC	8483.20.8080
Country of Origin	Mexico
