• Wide race and rollers and steel cage for high dynamic load ratings
• Race-mounted felt seal with flinger and misalignment sealing
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy ductile iron housing with Type E dimensions

Dimensions

Bolt Size (in)	3/4 in
Bore Diameter (in)	3.4375 in
Overall Length (in)	10.25 in
Overall Height to Inner Ring (in)	2.95 in
Pilot Diameter (in)	7.375 in
Overall Width (in)	10.25 in
Foot Height (in)	1.44 in
Overall Height (in)	4.47 in
Locking Collar Outside Diameter (in)	5.31 in
Housing Outside Diameter (in)	10.25 in
Mounting Surface to End of Housing (in)	1.31 in
Bolt Spacing (in)	6.094 in
Length Through Bore (in)	4.469 in
Bolt Circle (in)	8.625 in
Centerline to Outermost Bearing Face (in)	3.16 in

Technical Specifications

Rolling Element	Spherical Roller
Seal Type	Felt Labyrinth Seal
Bore Shape	Straight
Measure Units	Inch
Pilot Configuration	With Pilot
Maximum Speed (RPM)	2500 rpm
Housing Construction	Solid
Radial Dynamic Load Capacity (lb)	72,640 lb
Housing Base	Solid
Misalignment Type	Dynamic
Outer Ring Land Profile	Standard
End Cap	No
Housing Color	Black
Platform	USRB
Series	USFCE5000
Lubrication Method	Lubrication Fitting
Static Load Rating (lb)	105,628 lb
Shaft Locking Type	Single Set Collar
Radial Clearance	Standard
Housing Type	Flange, Cartridge
Fixed/Expansion	Fixed
Housing Style	Flange Block
Cage Material	Steel
Housing Material	Ductile Iron
Ability to Relubricate	Yes
Bolt Hole Shape	Round Hole
Bearing Insert Finish	Black Oxide Coated
Bearing Insert Material	52100 Bearing Steel, Black Oxided
Misalignment Capability	±2.0° Misalignment - Dynamic
Insert	USI5000-307
Lubricant	Lithium Complex NLGI 2 Grease
Housing Coating	POWDER COATED
Size Code	10
Grease Fitting Thread Size	1/4-28

General Specifications

UPC	662461365885
Weight	34.86 LB
Packaged Length	11.19 IN
Packaged Width	11.00 IN
Packaged Height	4.88 IN
HTC	8483.20.4080
Country of Origin	United States of America
