• Wide race and rollers and steel cage for high dynamic load ratings
• Race-mounted felt seal with flinger and misalignment sealing
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy cast iron housing

Dimensions

Bolt Size (in)	7/16 in
Bore Diameter (in)	1.7500 in
Overall Height (in)	2.88 in
Overall Width (in)	6.13 in
Overall Height to Inner Ring (in)	1.42 in
Pilot Diameter (in)	4.25 in
Foot Height (in)	0.47 in
Overall Length (in)	6.13 in
Locking Collar Outside Diameter (in)	2.75 in
Housing Outside Diameter (in)	6.13 in
Bolt Circle (in)	5.125 in
Mounting Surface to End of Housing (in)	1.44 in
Length Through Bore (in)	2.875 in
Centerline to Outermost Bearing Face (in)	1.44 in
Bolt Spacing (in)	3.625 in

Technical Specifications

Measure Units	Inch
Seal Type	Felt Labyrinth Seal
Rolling Element	Spherical Roller
Bore Shape	Straight
Pilot Configuration	With Pilot
Maximum Speed (RPM)	4000 rpm
Radial Dynamic Load Capacity (lb)	22,689 lb
Housing Construction	Solid
Outer Ring Land Profile	Standard
Platform	USRB
Misalignment Type	Dynamic
Housing Color	Black
End Cap	No
Series	USFC5000
Lubrication Method	Lubrication Fitting
Static Load Rating (lb)	28,021 lb
Housing Type	Flange, Cartridge
Fixed/Expansion	Expansion
Shaft Locking Type	Single Set Collar
Housing Style	Flange Block
Radial Clearance	Standard
Cage Material	Steel
Housing Material	Cast Iron
Ability to Relubricate	Yes
Bolt Hole Shape	Round Hole
Size Code	5
Grease Fitting Thread Size	1/4-28
Misalignment Capability	±2.0° Misalignment - Dynamic
Bearing Insert Finish	Black Oxide Coated
Bearing Insert Material	52100 Bearing Steel, Black Oxided
Housing Coating	POWDER COATED
Insert	USI5000-112
Lubricant	Lithium Complex NLGI 2 Grease

General Specifications

UPC	662461362556
Weight	7.50 LB
Packaged Length	6.38 IN
Packaged Width	6.31 IN
Packaged Height	3.88 IN
HTC	8483.20.4080
Country of Origin	Mexico
