• Wide race and rollers and steel cage for high dynamic load ratings
• Race-mounted felt seal with flinger and misalignment sealing
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy cast iron housing

Dimensions

Bolt Size (in)	3/4 in
Bore Diameter (in)	4 in
Pilot Diameter (in)	8.125 in
Overall Height to Inner Ring (in)	2.66 in
Overall Length (in)	10.88 in
Overall Height (in)	4.94 in
Foot Height (in)	0.97 in
Overall Width (in)	10.88 in
Housing Outside Diameter (in)	10.88 in
Locking Collar Outside Diameter (in)	6 in
Centerline to Outermost Bearing Face (in)	2.88 in
Bolt Circle (in)	9.375 in
Mounting Surface to End of Housing (in)	2.06 in
Length Through Bore (in)	4.938 in
Bolt Spacing (in)	6.625 in

Technical Specifications

Bore Shape	Straight
Seal Type	Felt Labyrinth Seal
Rolling Element	Spherical Roller
Measure Units	Inch
Pilot Configuration	With Pilot
Radial Dynamic Load Capacity (lb)	96,050 lb
Housing Base	Solid
Housing Construction	Solid
Maximum Speed (RPM)	2250 rpm
Misalignment Type	Dynamic
Outer Ring Land Profile	Standard
Platform	USRB
Housing Color	Black
End Cap	No
Series	USFC5000
Lubrication Method	Lubrication Fitting
Static Load Rating (lb)	136,151 lb
Fixed/Expansion	Fixed
Cage Material	Steel
Radial Clearance	Standard
Housing Material	Cast Iron
Shaft Locking Type	Single Set Collar
Housing Type	Flange, Cartridge
Housing Style	Flange Block
Ability to Relubricate	Yes
Bolt Hole Shape	Round Hole
Size Code	11
Misalignment Capability	±2.0° Misalignment - Dynamic
Insert	USI5000-400
Lubricant	Lithium Complex NLGI 2 Grease
Bearing Insert Material	52100 Bearing Steel, Black Oxided
Bearing Insert Finish	Black Oxide Coated
Housing Coating	POWDER COATED
Grease Fitting Thread Size	1/4-28

General Specifications

UPC	662461362464
Weight	39.73 LB
Packaged Length	11.19 IN
Packaged Width	11.00 IN
Packaged Height	4.88 IN
HTC	8483.20.4080
Country of Origin	United States of America
