• Wide race and rollers and steel cage for high dynamic load ratings
• Race-mounted double-lip contact seal with flinger and misalignment sealing
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy cast iron housing

Dimensions

Bolt Size (in)	5/8 in
Bore Diameter (in)	3 in
Overall Length (in)	8.75 in
Pilot Diameter (in)	6.375 in
Overall Height to Inner Ring (in)	2 in
Overall Height (in)	3.88 in
Foot Height (in)	0.72 in
Overall Width (in)	8.75 in
Locking Collar Outside Diameter (in)	4.52 in
Housing Outside Diameter (in)	8.75 in
Bolt Circle (in)	7.5 in
Bolt Spacing (in)	5.297 in
Length Through Bore (in)	3.875 in
Centerline to Outermost Bearing Face (in)	2.03 in
Mounting Surface to End of Housing (in)	1.84 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Spherical Roller
Seal Type	Multi-Lip Contact Seal
Measure Units	Inch
Pilot Configuration	With Pilot
Maximum Speed (RPM)	1600 rpm
Housing Construction	Solid
Radial Dynamic Load Capacity (lb)	47,447 lb
Platform	USRB
Misalignment Type	Dynamic
End Cap	No
Outer Ring Land Profile	Standard
Housing Color	Black
Series	USFC5000
Lubrication Method	Lubrication Fitting
Static Load Rating (lb)	65,610 lb
Housing Type	Flange, Cartridge
Cage Material	Steel
Housing Style	Flange Block
Fixed/Expansion	Fixed
Shaft Locking Type	Single Set Collar
Housing Material	Cast Iron
Radial Clearance	Standard
Ability to Relubricate	Yes
Bolt Hole Shape	Round Hole
Insert	USI5000-300-C
Size Code	9
Housing Coating	POWDER COATED
Grease Fitting Thread Size	1/4-28
Bearing Insert Material	52100 Bearing Steel, Black Oxided
Misalignment Capability	±2.0° Misalignment - Dynamic
Lubricant	Lithium Complex NLGI 2 Grease
Bearing Insert Finish	Black Oxide Coated

General Specifications

UPC	662461362341
Weight	25.33 LB
Packaged Length	8.88 IN
Packaged Width	8.88 IN
Packaged Height	3.88 IN
HTC	8483.20.4080
Country of Origin	Mexico
