• Wide race and rollers and steel cage for high dynamic load ratings
• Race-mounted felt seal with flinger and misalignment sealing
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy cast iron housing

Dimensions

Bolt Size (in)	5/8 in
Bore Diameter (in)	2.6875 in
Overall Width (in)	8.75 in
Pilot Diameter (in)	6.375 in
Overall Length (in)	8.75 in
Overall Height to Inner Ring (in)	2 in
Foot Height (in)	0.72 in
Overall Height (in)	3.88 in
Housing Outside Diameter (in)	8.75 in
Locking Collar Outside Diameter (in)	4.52 in
Bolt Circle (in)	7.5 in
Length Through Bore (in)	3.875 in
Centerline to Outermost Bearing Face (in)	2.03 in
Mounting Surface to End of Housing (in)	1.84 in
Bolt Spacing (in)	5.297 in

Technical Specifications

Rolling Element	Spherical Roller
Seal Type	Felt Labyrinth Seal
Bore Shape	Straight
Measure Units	Inch
Pilot Configuration	With Pilot
Radial Dynamic Load Capacity (lb)	47,447 lb
Maximum Speed (RPM)	3000 rpm
Housing Construction	Solid
Housing Base	Solid
Platform	USRB
Misalignment Type	Dynamic
Outer Ring Land Profile	Standard
Housing Color	Black
End Cap	No
Series	USFC5000
Lubrication Method	Lubrication Fitting
Static Load Rating (lb)	65,610 lb
Housing Type	Flange, Cartridge
Cage Material	Steel
Housing Style	Flange Block
Radial Clearance	Standard
Housing Material	Cast Iron
Shaft Locking Type	Single Set Collar
Fixed/Expansion	Fixed
Ability to Relubricate	Yes
Bolt Hole Shape	Round Hole
Insert	USI5000-211
Bearing Insert Finish	Black Oxide Coated
Misalignment Capability	±2.0° Misalignment - Dynamic
Lubricant	Lithium Complex NLGI 2 Grease
Size Code	9
Bearing Insert Material	52100 Bearing Steel, Black Oxided
Housing Coating	POWDER COATED
Grease Fitting Thread Size	1/4-28

General Specifications

UPC	662461363478
Weight	21.83 LB
Packaged Length	8.88 IN
Packaged Width	8.88 IN
Packaged Height	3.88 IN
HTC	8483.20.4080
Country of Origin	Mexico
