• Wide race and rollers and steel cage for high dynamic load ratings
• Race-mounted double-lip contact seal with flinger and misalignment sealing
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy cast iron housing

Dimensions

Bolt Size (in)	1/2 in
Bore Diameter (in)	2.5000 in
Overall Height to Inner Ring (in)	1.81 in
Overall Length (in)	7.63 in
Foot Height (in)	0.59 in
Overall Height (in)	3.43 in
Overall Width (in)	7.63 in
Pilot Diameter (in)	5.5 in
Locking Collar Outside Diameter (in)	4.1 in
Housing Outside Diameter (in)	7.63 in
Length Through Bore (in)	3.375 in
Bolt Circle (in)	6.5 in
Mounting Surface to End of Housing (in)	1.63 in
Bolt Spacing (in)	4.594 in
Centerline to Outermost Bearing Face (in)	1.75 in

Technical Specifications

Seal Type	Multi-Lip Contact Seal
Bore Shape	Straight
Measure Units	Inch
Rolling Element	Spherical Roller
Pilot Configuration	With Pilot
Housing Construction	Solid
Radial Dynamic Load Capacity (lb)	44,691 lb
Maximum Speed (RPM)	1750 rpm
Housing Color	Black
Outer Ring Land Profile	Standard
End Cap	No
Platform	USRB
Misalignment Type	Dynamic
Series	USFC5000
Lubrication Method	Lubrication Fitting
Static Load Rating (lb)	59,535 lb
Housing Material	Cast Iron
Radial Clearance	Standard
Fixed/Expansion	Fixed
Housing Style	Flange Block
Housing Type	Flange, Cartridge
Shaft Locking Type	Single Set Collar
Cage Material	Steel
Ability to Relubricate	Yes
Bolt Hole Shape	Round Hole
Housing Coating	POWDER COATED
Bearing Insert Finish	Black Oxide Coated
Insert	USI5000-208-C
Bearing Insert Material	52100 Bearing Steel, Black Oxided
Size Code	8
Misalignment Capability	±2.0° Misalignment - Dynamic
Lubricant	Lithium Complex NLGI 2 Grease
Grease Fitting Thread Size	1/4-28

General Specifications

UPC	662461363461
Weight	14.13 LB
Packaged Length	7.88 IN
Packaged Width	7.75 IN
Packaged Height	4.69 IN
HTC	8483.20.4080
Country of Origin	Mexico
