• Wide race and rollers and steel cage for high dynamic load ratings
• Race-mounted felt seal with flinger and misalignment sealing
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy cast iron housing

Dimensions

Bolt Size (in)	7/16 in
Bore Diameter (in)	1.7500 in
Pilot Diameter (in)	4.25 in
Overall Height to Inner Ring (in)	1.42 in
Overall Length (in)	6.13 in
Overall Width (in)	6.13 in
Foot Height (in)	0.47 in
Overall Height (in)	2.88 in
Locking Collar Outside Diameter (in)	2.75 in
Housing Outside Diameter (in)	6.13 in
Bolt Spacing (in)	3.625 in
Bolt Circle (in)	5.125 in
Mounting Surface to End of Housing (in)	1.44 in
Centerline to Outermost Bearing Face (in)	1.44 in
Length Through Bore (in)	2.875 in

Technical Specifications

Bore Shape	Straight
Measure Units	Inch
Rolling Element	Spherical Roller
Seal Type	Felt Labyrinth Seal
Pilot Configuration	With Pilot
Housing Construction	Solid
Maximum Speed (RPM)	4000 rpm
Radial Dynamic Load Capacity (lb)	22,689 lb
Platform	USRB
Housing Color	Black
Misalignment Type	Dynamic
End Cap	No
Outer Ring Land Profile	Standard
Series	USFC5000
Lubrication Method	Lubrication Fitting
Static Load Rating (lb)	28,021 lb
Housing Style	Flange Block
Cage Material	Steel
Radial Clearance	Standard
Fixed/Expansion	Fixed
Shaft Locking Type	Single Set Collar
Housing Type	Flange, Cartridge
Housing Material	Cast Iron
Bolt Hole Shape	Round Hole
Ability to Relubricate	Yes
Misalignment Capability	±2.0° Misalignment - Dynamic
Grease Fitting Thread Size	1/4-28
Lubricant	Lithium Complex NLGI 2 Grease
Housing Coating	POWDER COATED
Size Code	5
Bearing Insert Finish	Black Oxide Coated
Insert	USI5000-112
Bearing Insert Material	52100 Bearing Steel, Black Oxided

General Specifications

UPC	662461363348
Weight	7.50 LB
Packaged Length	6.38 IN
Packaged Width	6.31 IN
Packaged Height	3.88 IN
HTC	8483.20.4080
Country of Origin	Mexico
