• Wide race and rollers and steel cage for high dynamic load ratings
• Race-mounted felt seal with flinger and misalignment sealing
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy cast iron housing

Dimensions

Bolt Size (in)	5/8 in
Bore Diameter (in)	2.4375 in
Overall Height to Inner Ring (in)	3.48 in
Overall Width (in)	6.75 in
Housing Width (in)	6.75 in
Overall Length (in)	6.75 in
Overall Height (in)	3.48 in
Foot Height (in)	1 in
Locking Collar Outside Diameter (in)	4 in
Bolt Spacing (in)	5.38 in
Length Through Bore (in)	3.38 in
Bolt Circle (in)	7.594 in

Technical Specifications

Seal Type	Felt Labyrinth Seal
Measure Units	Inch
Rolling Element	Spherical Roller
Bore Shape	Straight
Maximum Speed (RPM)	3250 rpm
Pilot Configuration	No Pilot
Radial Dynamic Load Capacity (lb)	44,691 lb
Housing Construction	Solid
Misalignment Type	Dynamic
Outer Ring Land Profile	Standard
End Cap	No
Platform	USRB
Housing Color	Gray
Series	USFBE5000
Lubrication Method	Lubrication Fitting
Static Load Rating (lb)	59,535 lb
Fixed/Expansion	Fixed
Shaft Locking Type	Single Set Collar
Housing Type	Flange, Four Bolt
Cage Material	Steel
Radial Clearance	Standard
Housing Style	Flange Block
Housing Material	Ductile Iron
Bolt Hole Shape	Round Hole
Ability to Relubricate	Yes
Grease Fitting Thread Size	1/8 NPT
Bearing Insert Material	52100 Bearing Steel, Black Oxided
Bearing Insert Finish	Black Oxide Coated
Misalignment Capability	±2.0° Misalignment - Dynamic
Size Code	8
Insert	USI5000-207
Lubricant	Lithium Complex NLGI 2 Grease

General Specifications

UPC	662461365144
Weight	19.43 LB
Packaged Length	8.13 IN
Packaged Width	7.94 IN
Packaged Height	3.50 IN
HTC	8483.20.4080
Country of Origin	Mexico
