• Wide race and rollers and steel cage for high dynamic load ratings
• Race-mounted felt seal with flinger and misalignment sealing
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy cast iron housing

Dimensions

Bolt Size (in)	1/2 in
Bore Diameter (in)	1.5000 in
Housing Width (in)	4.63 in
Overall Height (in)	2.83 in
Foot Height (in)	0.75 in
Overall Length (in)	4.63 in
Overall Height to Inner Ring (in)	2.83 in
Overall Width (in)	4.63 in
Locking Collar Outside Diameter (in)	2.77 in
Length Through Bore (in)	2.75 in
Bolt Circle (in)	5 in
Bolt Spacing (in)	3.53 in

Technical Specifications

Bore Shape	Straight
Measure Units	Inch
Maximum Speed (RPM)	4000 rpm
Rolling Element	Spherical Roller
Seal Type	Felt Labyrinth Seal
Pilot Configuration	No Pilot
Radial Dynamic Load Capacity (lb)	20,368 lb
Housing Construction	Solid
Misalignment Type	Dynamic
Housing Color	Gray
End Cap	No
Platform	USRB
Outer Ring Land Profile	Standard
Series	USFB5000
Lubrication Method	Lubrication Fitting
Static Load Rating (lb)	23,609 lb
Housing Material	Cast Iron
Shaft Locking Type	Single Set Collar
Housing Type	Flange, Four Bolt
Fixed/Expansion	Expansion
Radial Clearance	Standard
Housing Style	Flange Block
Cage Material	Steel
Ability to Relubricate	Yes
Bolt Hole Shape	Round Hole
Grease Fitting Thread Size	1/8 NPT
Misalignment Capability	±2.0° Misalignment - Dynamic
Bearing Insert Material	52100 Bearing Steel, Black Oxided
Lubricant	Lithium Complex NLGI 2 Grease
Bearing Insert Finish	Black Oxide Coated
Insert	USI5000-108
Size Code	4

General Specifications

UPC	662461361597
Weight	6.39 LB
Packaged Length	5.50 IN
Packaged Width	3.13 IN
Packaged Height	5.56 IN
HTC	8483.20.4080
Country of Origin	Mexico
