• Wide race and rollers and steel cage for high dynamic load ratings
• Race-mounted double-lip contact seal with flinger and misalignment sealing
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy cast iron housing

Dimensions

Bolt Size (in)	5/8 in
Bore Diameter (in)	2.4375 in
Foot Height (in)	1.03 in
Overall Height to Inner Ring (in)	3.48 in
Overall Width (in)	6.13 in
Overall Height (in)	3.48 in
Overall Length (in)	6.13 in
Housing Width (in)	6.13 in
Locking Collar Outside Diameter (in)	4 in
Bolt Circle (in)	6.75 in
Bolt Spacing (in)	4.77 in
Length Through Bore (in)	3.38 in

Technical Specifications

Seal Type	Multi-Lip Contact Seal
Bore Shape	Straight
Maximum Speed (RPM)	1750 rpm
Rolling Element	Spherical Roller
Measure Units	Inch
Pilot Configuration	No Pilot
Radial Dynamic Load Capacity (lb)	44,691 lb
Housing Construction	Solid
Platform	USRB
Misalignment Type	Dynamic
Outer Ring Land Profile	Standard
Housing Color	Gray
End Cap	No
Series	USFB5000
Lubrication Method	Lubrication Fitting
Static Load Rating (lb)	59,535 lb
Radial Clearance	Standard
Fixed/Expansion	Fixed
Shaft Locking Type	Single Set Collar
Housing Material	Cast Iron
Housing Type	Flange, Four Bolt
Housing Style	Flange Block
Cage Material	Steel
Bolt Hole Shape	Round Hole
Ability to Relubricate	Yes
Insert	USI5000-207-C
Grease Fitting Thread Size	1/8 NPT
Size Code	8
Bearing Insert Material	52100 Bearing Steel, Black Oxided
Lubricant	Lithium Complex NLGI 2 Grease
Misalignment Capability	±2.0° Misalignment - Dynamic
Bearing Insert Finish	Black Oxide Coated

General Specifications

UPC	662461361245
Weight	15.82 LB
Packaged Length	6.38 IN
Packaged Width	6.31 IN
Packaged Height	3.88 IN
HTC	8483.20.4080
Country of Origin	Mexico
