• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Left-Hand Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Ball Width (in)	0.5 in
Thread Size	#3/8-24
Housing Width (in)	0.406 in
Ball Diameter (in)	0.718 in
Ball Flat Diameter (in)	0.517 in
Thread Length (in)	0.906 in
Base Diameter (in)	0.688 in
Head Diameter (in)	1 in
Length to Center of Ball (in)	1.63 in

Technical Specifications

Construction	Three-Piece Rod End with Zerk Fitting
Zerk Fitting SW	N
Misalignment Angle - a Deg. +/-	6
Housing Style	Female Rod End
Race Material	Carbon Steel - corrosion resistant plating
Configuration	Female
Product Selection Available SW	Y
Axial Load	445
Outer Material	Carbon Steel - Corrosion Resistant Plating
Series	Precision
Across Wrench Flats	0.562
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Lubrication Type	Grease
Thread Type	UNF
Bearing Type	Rod End
Product Type	TR
Lubrication	No Zerk Fitting
Max Static Radial Load	4,450
Type	Female Rod End
Thread	LH
Bore Size (in)	0.3750 in
Class	Precision
Lubrication Method	No Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	None

General Specifications

UPC	662288719502
Weight	0.57 LB
Packaged Length	4.55 IN
Packaged Width	1.90 IN
Packaged Height	1.20 IN
HTC	8483.30.8055
Country of Origin	Mexico
