• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Left-Hand Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Base Diameter (in)	0.469 in
Ball Flat Diameter (in)	0.331 in
Head Diameter (in)	0.75 in
Thread Length (in)	0.719 in
Housing Width (in)	0.281 in
Thread Size	#1/4-28
Ball Diameter (in)	0.5 in
Ball Width (in)	0.375 in
Length to Center of Ball (in)	1.31 in

Technical Specifications

Misalignment Angle - a Deg. +/-	8
Outer Material	Carbon Steel - Corrosion Resistant Plating
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Series	Precision
Lubrication Type	Grease
Bearing Type	Rod End
Product Selection Available SW	Y
Housing Style	Female Rod End
Thread Type	UNF
Zerk Fitting SW	N
Race Material	Carbon Steel - corrosion resistant plating
Axial Load	270
Configuration	Female
Construction	Three-Piece Rod End with Zerk Fitting
Product Type	TR
Across Wrench Flats	0.375
Max Static Radial Load	2,700
Lubrication	No Zerk Fitting
Type	Female Rod End
Thread	LH
Class	Precision
Bore Size (in)	0.2500 in
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288719489
Weight	0.47 LB
Packaged Length	4.35 IN
Packaged Width	2.15 IN
Packaged Height	0.45 IN
HTC	8483.30.8055
Country of Origin	Mexico
