• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Left-Hand Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Ball Flat Diameter (in)	0.978 in
Housing Width (in)	0.687 in
Ball Diameter (in)	1.312 in
Thread Length (in)	1.719 in
Head Diameter (in)	1.75 in
Thread Size	#3/4-16
Ball Width (in)	0.875 in
Base Diameter (in)	1.125 in
Length to Center of Ball (in)	2.88 in

Technical Specifications

Configuration	Female
Housing Style	Female Rod End
Lubrication Type	Grease
Axial Load	1,130
Product Type	TR
Zerk Fitting SW	N
Thread Type	UNF
Bearing Type	Rod End
Series	Precision
Race Material	Carbon Steel - corrosion resistant plating
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Misalignment Angle - a Deg. +/-	7
Product Selection Available SW	Y
Outer Material	Carbon Steel - Corrosion Resistant Plating
Construction	Three-Piece Rod End with Zerk Fitting
Across Wrench Flats	1
Lubrication	No Zerk Fitting
Type	Female Rod End
Max Static Radial Load	11,300
Thread	LH
Class	Precision
Bore Size (in)	0.7500 in
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288719540
Weight	0.68 LB
Packaged Length	5.55 IN
Packaged Width	2.20 IN
Packaged Height	1.40 IN
HTC	8483.30.8055
Country of Origin	Mexico
