• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Left-Hand Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Housing Width (in)	0.562 in
Ball Flat Diameter (in)	0.839 in
Base Diameter (in)	1 in
Thread Size	#5/8-18
Thread Length (in)	1.469 in
Head Diameter (in)	1.5 in
Ball Diameter (in)	1.125 in
Ball Width (in)	0.75 in
Length to Center of Ball (in)	2.5 in

Technical Specifications

Across Wrench Flats	0.875
Product Selection Available SW	Y
Misalignment Angle - a Deg. +/-	8
Series	Precision
Product Type	TR
Configuration	Female
Construction	Three-Piece Rod End with Zerk Fitting
Axial Load	805
Outer Material	Carbon Steel - Corrosion Resistant Plating
Race Material	Carbon Steel - corrosion resistant plating
Bearing Type	Rod End
Housing Style	Female Rod End
Lubrication Type	Grease
Zerk Fitting SW	Y
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Thread Type	UNF
Lubrication	Zerk Fitting
Thread	LH
Type	Female Rod End
Max Static Radial Load	8,050
Class	Precision
Bore Size (in)	0.6250 in
Lubrication Method	Fitting
Ability to Relubricate	Yes
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288720263
Weight	0.48 LB
Packaged Length	5.30 IN
Packaged Width	5.00 IN
Packaged Height	3.00 IN
HTC	8483.30.8055
Country of Origin	Mexico
