• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Left-Hand Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Ball Width (in)	0.625 in
Thread Size	#1/2-20
Housing Width (in)	0.5 in
Head Diameter (in)	1.312 in
Ball Diameter (in)	0.937 in
Thread Length (in)	1.469 in
Ball Flat Diameter (in)	0.698 in
Length to Center of Ball (in)	2.44 in

Technical Specifications

Bearing Type	Rod End
Configuration	Male
Construction	Three-Piece Rod End with Zerk Fitting
Series	Precision
Lubrication Type	Grease
Race Material	Carbon Steel - corrosion resistant plating
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Outer Material	Carbon Steel - Corrosion Resistant Plating
Thread Type	UNF
Axial Load	700
Misalignment Angle - a Deg. +/-	6
Housing Style	Male Rod End
Zerk Fitting SW	Y
Product Selection Available SW	Y
Product Type	TRE
Lubrication	Zerk Fitting
Type	Male Rod End
Max Static Radial Load	7,000
Thread	LH
Class	Precision
Bore Size (in)	0.5000 in
Lubrication Method	Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	Yes

General Specifications

UPC	662288718734
Weight	0.69 LB
Packaged Length	1.95 IN
Packaged Width	4.75 IN
Packaged Height	0.85 IN
HTC	8483.30.8055
Country of Origin	Mexico
