• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Left-Hand Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Thread Length (in)	1.219 in
Head Diameter (in)	0.875 in
Housing Width (in)	0.344 in
Ball Diameter (in)	0.625 in
Ball Width (in)	0.437 in
Thread Size	#5/16-24
Ball Flat Diameter (in)	0.447 in
Length to Center of Ball (in)	1.88 in

Technical Specifications

Series	Precision
Construction	Three-Piece Rod End with Zerk Fitting
Race Material	Carbon Steel - corrosion resistant plating
Misalignment Angle - a Deg. +/-	7
Lubrication Type	Grease
Zerk Fitting SW	N
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Outer Material	Carbon Steel - Corrosion Resistant Plating
Housing Style	Male Rod End
Configuration	Male
Product Selection Available SW	Y
Axial Load	250
Thread Type	UNF
Bearing Type	Rod End
Product Type	TRE
Max Static Radial Load	2,500
Thread	LH
Lubrication	No Zerk Fitting
Type	Male Rod End
Class	Precision
Bore Size (in)	0.3125 in
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288719588
Weight	0.49 LB
Packaged Length	5.00 IN
Packaged Width	2.10 IN
Packaged Height	0.45 IN
HTC	8483.30.8055
Country of Origin	Mexico
