• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads
• One-Piece Carbon Steel Outer Race
• Y Stud

Dimensions

Ball Flat Diameter (in)	0.698 in
Ball Diameter (in)	0.937 in
Thread Size	#1/2-20
Thread Length (in)	1.469 in
Head Diameter (in)	1.312 in
Ball Width (in)	0.625 in
Housing Width (in)	0.5 in
Stud Length to Hex (in)	1.13 in
Stud Thread Length (in)	1 in
Length to Center of Ball (in)	2.44 in
Stud Length to Center of Ball (in)	2 in

Technical Specifications

Series	Precision
Zerk Fitting SW	N
Lubrication Type	Grease
Axial Load	700
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Product Selection Available SW	N
Bearing Type	Rod End
Configuration	Male
Product Type	TRE
Thread Type	UNF
Y Stud Material	Carbon Steel - corrosion resistant plating
Housing Style	Male Rod End
Race Material	Carbon Steel - corrosion resistant plating
Construction	Three-Piece Rod End with Y Stud and Zerk Fitting
Outer Material	Carbon Steel - Corrosion Resistant Plating
Max Static Radial Load	7,000
Thread	RH
Misalignment Angle B3	24.3
Type	Male Rod End
Lubrication	No Zerk Fitting
Class	Precision
Bore Size (in)	0.5000 in
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288720515
Weight	0.39 LB
Packaged Length	3.09 IN
Packaged Width	2.31 IN
Packaged Height	1.31 IN
HTC	8483.30.8055
Country of Origin	Mexico
