• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Housing Width (in)	0.5 in
Thread Size	#1/2-20
Head Diameter (in)	1.312 in
Ball Width (in)	0.625 in
Ball Flat Diameter (in)	0.698 in
Thread Length (in)	1.469 in
Ball Diameter (in)	0.937 in
Length to Center of Ball (in)	2.44 in

Technical Specifications

Construction	Three-Piece Rod End with Zerk Fitting
Configuration	Male
Misalignment Angle - a Deg. +/-	6
Housing Style	Male Rod End
Outer Material	Carbon Steel - Corrosion Resistant Plating
Product Selection Available SW	Y
Series	Precision
Lubrication Type	Grease
Product Type	TRE
Zerk Fitting SW	N
Bearing Type	Rod End
Axial Load	700
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Thread Type	UNF
Race Material	Carbon Steel - corrosion resistant plating
Thread	RH
Max Static Radial Load	7,000
Lubrication	No Zerk Fitting
Type	Male Rod End
Bore Size (in)	0.5000 in
Class	Precision
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288718703
Weight	0.27 LB
Packaged Length	2.40 IN
Packaged Width	3.35 IN
Packaged Height	1.00 IN
HTC	8483.30.8055
Country of Origin	Mexico
