• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Head Diameter (in)	1.125 in
Thread Size	#7/16-20
Ball Width (in)	0.562 in
Ball Diameter (in)	0.812 in
Ball Flat Diameter (in)	0.586 in
Thread Length (in)	1.344 in
Housing Width (in)	0.437 in
Length to Center of Ball (in)	2.13 in

Technical Specifications

Construction	Three-Piece Rod End with Zerk Fitting
Zerk Fitting SW	Y
Thread Type	UNF
Bearing Type	Rod End
Series	Precision
Housing Style	Male Rod End
Lubrication Type	Grease
Outer Material	Carbon Steel - Corrosion Resistant Plating
Product Type	TRE
Race Material	Carbon Steel - corrosion resistant plating
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Misalignment Angle - a Deg. +/-	7
Product Selection Available SW	Y
Axial Load	500
Configuration	Male
Lubrication	Zerk Fitting
Thread	RH
Type	Male Rod End
Max Static Radial Load	5,000
Bore Size (in)	0.4375 in
Class	Precision
Lubrication Method	Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	Yes

General Specifications

UPC	662288719953
Weight	0.18 LB
Packaged Length	2.30 IN
Packaged Width	2.50 IN
Packaged Height	0.65 IN
HTC	8483.30.8055
Country of Origin	Mexico
