• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Ball Diameter (in)	0.812 in
Head Diameter (in)	1.125 in
Thread Length (in)	1.344 in
Housing Width (in)	0.437 in
Ball Flat Diameter (in)	0.586 in
Ball Width (in)	0.562 in
Thread Size	#7/16-20
Length to Center of Ball (in)	2.13 in

Technical Specifications

Series	Precision
Construction	Three-Piece Rod End with Zerk Fitting
Race Material	Carbon Steel - corrosion resistant plating
Lubrication Type	Grease
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Zerk Fitting SW	N
Axial Load	500
Bearing Type	Rod End
Product Selection Available SW	Y
Misalignment Angle - a Deg. +/-	7
Configuration	Male
Outer Material	Carbon Steel - Corrosion Resistant Plating
Housing Style	Male Rod End
Product Type	TRE
Thread Type	UNF
Max Static Radial Load	5,000
Type	Male Rod End
Lubrication	No Zerk Fitting
Thread	RH
Bore Size (in)	0.4375 in
Class	Precision
Lubrication Method	No Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	None

General Specifications

UPC	662288719205
Weight	0.19 LB
Packaged Length	2.45 IN
Packaged Width	2.40 IN
Packaged Height	0.65 IN
HTC	8483.30.8055
Country of Origin	Mexico
