• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Ball Width (in)	0.437 in
Head Diameter (in)	0.875 in
Ball Flat Diameter (in)	0.447 in
Ball Diameter (in)	0.625 in
Thread Length (in)	1.219 in
Thread Size	#5/16-24
Housing Width (in)	0.344 in
Length to Center of Ball (in)	1.88 in

Technical Specifications

Zerk Fitting SW	Y
Product Type	TRE
Thread Type	UNF
Outer Material	Carbon Steel - Corrosion Resistant Plating
Product Selection Available SW	Y
Bearing Type	Rod End
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Series	Precision
Configuration	Male
Lubrication Type	Grease
Race Material	Carbon Steel - corrosion resistant plating
Housing Style	Male Rod End
Axial Load	250
Misalignment Angle - a Deg. +/-	7
Construction	Three-Piece Rod End with Zerk Fitting
Max Static Radial Load	2,500
Thread	RH
Type	Male Rod End
Lubrication	Zerk Fitting
Class	Precision
Bore Size (in)	0.3125 in
Lubrication Method	Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	Yes

General Specifications

UPC	662288719939
Weight	0.49 LB
Packaged Length	2.20 IN
Packaged Width	4.70 IN
Packaged Height	0.45 IN
HTC	8483.30.8055
Country of Origin	Mexico
