• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• One-Piece Carbon Steel Outer Race
• Y Stud

Dimensions

Ball Width (in)	0.625 in
Head Diameter (in)	1.312 in
Ball Flat Diameter (in)	0.698 in
Thread Size	#1/2-20
Ball Diameter (in)	0.937 in
Housing Width (in)	0.5 in
Base Diameter (in)	0.875 in
Thread Length (in)	1.156 in
Stud Length to Center of Ball (in)	2 in
Stud Length to Hex (in)	1.13 in
Stud Thread Length (in)	1 in
Length to Center of Ball (in)	2.13 in

Technical Specifications

Series	Precision
Product Selection Available SW	N
Construction	Three-Piece Rod End with Y Stud and Zerk Fitting
Product Type	TR
Bearing Type	Rod End
Lubrication Type	Grease
Thread Type	UNF
Outer Material	Carbon Steel - Corrosion Resistant Plating
Across Wrench Flats	0.75
Y Stud Material	Carbon Steel - corrosion resistant plating
Axial Load	740
Configuration	Female
Race Material	Carbon Steel - corrosion resistant plating
Housing Style	Female Rod End
Zerk Fitting SW	N
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Misalignment Angle B3	24.3
Lubrication	No Zerk Fitting
Max Static Radial Load	7,400
Thread	RH
Type	Female Rod End
Class	Precision
Bore Size (in)	0.5000 in
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288720430
Weight	0.44 LB
Packaged Length	2.78 IN
Packaged Width	2.31 IN
Packaged Height	1.31 IN
HTC	8483.30.8055
Country of Origin	Mexico
