• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Ball Flat Diameter (in)	0.586 in
Ball Diameter (in)	0.812 in
Thread Length (in)	1.031 in
Base Diameter (in)	0.75 in
Head Diameter (in)	1.125 in
Ball Width (in)	0.562 in
Thread Size	#7/16-20
Housing Width (in)	0.437 in
Length to Center of Ball (in)	1.81 in

Technical Specifications

Product Type	TR
Lubrication Type	Grease
Bearing Type	Rod End
Construction	Three-Piece Rod End with Zerk Fitting
Outer Material	Carbon Steel - Corrosion Resistant Plating
Housing Style	Female Rod End
Product Selection Available SW	Y
Configuration	Female
Series	Precision
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Misalignment Angle - a Deg. +/-	7
Race Material	Carbon Steel - corrosion resistant plating
Thread Type	UNF
Axial Load	535
Across Wrench Flats	0.625
Zerk Fitting SW	Y
Type	Female Rod End
Lubrication	Zerk Fitting
Max Static Radial Load	5,350
Thread	RH
Bore Size (in)	0.4375 in
Class	Precision
Lubrication Method	Fitting
Ability to Relubricate	Yes
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288719878
Weight	0.20 LB
Packaged Length	2.60 IN
Packaged Width	2.40 IN
Packaged Height	0.95 IN
HTC	8483.30.8055
Country of Origin	Mexico
