• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Ball Diameter (in)	0.812 in
Thread Size	#7/16-20
Base Diameter (in)	0.75 in
Ball Width (in)	0.562 in
Housing Width (in)	0.437 in
Head Diameter (in)	1.125 in
Ball Flat Diameter (in)	0.586 in
Thread Length (in)	1.031 in
Length to Center of Ball (in)	1.81 in

Technical Specifications

Product Type	TR
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Outer Material	Carbon Steel - Corrosion Resistant Plating
Series	Precision
Lubrication Type	Grease
Misalignment Angle - a Deg. +/-	7
Race Material	Carbon Steel - corrosion resistant plating
Housing Style	Female Rod End
Product Selection Available SW	Y
Construction	Three-Piece Rod End with Zerk Fitting
Configuration	Female
Thread Type	UNF
Bearing Type	Rod End
Across Wrench Flats	0.625
Zerk Fitting SW	N
Axial Load	535
Max Static Radial Load	5,350
Lubrication	No Zerk Fitting
Thread	RH
Type	Female Rod End
Bore Size (in)	0.4375 in
Class	Precision
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288719120
Weight	0.19 LB
Packaged Length	2.60 IN
Packaged Width	2.90 IN
Packaged Height	0.75 IN
HTC	8483.30.8055
Country of Origin	Mexico
