• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Head Diameter (in)	0.75 in
Housing Width (in)	0.281 in
Thread Length (in)	0.719 in
Base Diameter (in)	0.469 in
Ball Flat Diameter (in)	0.331 in
Ball Width (in)	0.375 in
Thread Size	#1/4-28
Ball Diameter (in)	0.5 in
Length to Center of Ball (in)	1.31 in

Technical Specifications

Series	Precision
Construction	Three-Piece Rod End with Zerk Fitting
Across Wrench Flats	0.375
Configuration	Female
Misalignment Angle - a Deg. +/-	8
Product Selection Available SW	Y
Outer Material	Carbon Steel - Corrosion Resistant Plating
Bearing Type	Rod End
Thread Type	UNF
Zerk Fitting SW	N
Housing Style	Female Rod End
Lubrication Type	Grease
Product Type	TR
Race Material	Carbon Steel - corrosion resistant plating
Axial Load	270
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Max Static Radial Load	2,700
Thread	RH
Lubrication	No Zerk Fitting
Type	Female Rod End
Class	Precision
Bore Size (in)	0.2500 in
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288719090
Weight	0.05 LB
Packaged Length	4.45 IN
Packaged Width	2.05 IN
Packaged Height	0.45 IN
HTC	8483.30.8055
Country of Origin	Mexico
