• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Head Diameter (in)	0.625 in
Ball Flat Diameter (in)	0.306 in
Thread Length (in)	0.531 in
Housing Width (in)	0.25 in
Ball Diameter (in)	0.437 in
Ball Width (in)	0.312 in
Thread Size	#10-32
Base Diameter (in)	0.375 in
Length to Center of Ball (in)	1.06 in

Technical Specifications

Configuration	Female
Thread Type	UNF
Series	Precision
Lubrication Type	Grease
Race Material	Carbon Steel - corrosion resistant plating
Bearing Type	Rod End
Construction	Three-Piece Rod End with Zerk Fitting
Outer Material	Carbon Steel - Corrosion Resistant Plating
Axial Load	185
Product Type	TR
Zerk Fitting SW	N
Across Wrench Flats	0.312
Product Selection Available SW	Y
Misalignment Angle - a Deg. +/-	6.5
Housing Style	Female Rod End
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Type	Female Rod End
Lubrication	No Zerk Fitting
Max Static Radial Load	1,850
Thread	RH
Bore Size (in)	0.1875 in
Class	Precision
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288719083
Weight	0.45 LB
Packaged Length	4.30 IN
Packaged Width	2.20 IN
Packaged Height	0.40 IN
HTC	8483.30.8055
Country of Origin	Mexico
