• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Thread Size	#1 1/4-12
Ball Width (in)	1.375 in
Head Diameter (in)	2.75 in
Ball Flat Diameter (in)	1.269 in
Thread Length (in)	2.094 in
Ball Diameter (in)	1.875 in
Base Diameter (in)	1.688 in
Housing Width (in)	1 in
Length to Center of Ball (in)	4.13 in

Technical Specifications

Series	Precision
Outer Material	Carbon Steel - Corrosion Resistant Plating
Across Wrench Flats	1.5
Construction	Three-Piece Rod End with Zerk Fitting
Lubrication Type	Grease
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Race Material	Carbon Steel - corrosion resistant plating
Housing Style	Female Rod End
Product Selection Available SW	Y
Bearing Type	Rod End
Misalignment Angle - a Deg. +/-	8.5
Thread Type	UNF
Configuration	Female
Axial Load	2,100
Product Type	TR
Zerk Fitting SW	N
Lubrication	No Zerk Fitting
Thread	RH
Type	Female Rod End
Max Static Radial Load	21,000
Bore Size (in)	1 in
Class	Precision
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288719151
Weight	2.26 LB
Packaged Length	5.90 IN
Packaged Width	3.10 IN
Packaged Height	1.40 IN
HTC	8483.30.8055
Country of Origin	Mexico
