• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• One-Piece Carbon Steel Outer Race
• Y Stud

Dimensions

Base Diameter (in)	1.125 in
Ball Diameter (in)	1.312 in
Thread Length (in)	1.719 in
Head Diameter (in)	1.75 in
Housing Width (in)	0.687 in
Ball Flat Diameter (in)	0.978 in
Thread Size	#3/4-16
Ball Width (in)	0.875 in
Stud Length to Hex (in)	1.81 in
Length to Center of Ball (in)	2.88 in
Stud Thread Length (in)	1.625 in
Stud Length to Center of Ball (in)	3 in

Technical Specifications

Bearing Type	Rod End
Outer Material	Carbon Steel - Corrosion Resistant Plating
Configuration	Female
Construction	Three-Piece Rod End with Y Stud and Zerk Fitting
Product Type	TR
Thread Type	UNF
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Lubrication Type	Grease
Race Material	Carbon Steel - corrosion resistant plating
Series	Precision
Zerk Fitting SW	Y
Housing Style	Female Rod End
Product Selection Available SW	N
Y Stud Material	Carbon Steel - corrosion resistant plating
Axial Load	1,130
Across Wrench Flats	1
Misalignment Angle B3	22.7
Lubrication	Zerk Fitting
Thread	RH
Type	Female Rod End
Max Static Radial Load	11,300
Bore Size (in)	0.7500 in
Class	Precision
Lubrication Method	Fitting
Ability to Relubricate	Yes
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288720768
Weight	1.08 LB
Packaged Length	3.75 IN
Packaged Width	3.44 IN
Packaged Height	1.75 IN
HTC	8483.30.8055
Country of Origin	Mexico
