• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Thread Size	#3/4-16
Ball Flat Diameter (in)	0.978 in
Base Diameter (in)	1.125 in
Ball Width (in)	0.875 in
Ball Diameter (in)	1.312 in
Housing Width (in)	0.687 in
Thread Length (in)	1.719 in
Head Diameter (in)	1.75 in
Length to Center of Ball (in)	2.88 in

Technical Specifications

Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Configuration	Female
Zerk Fitting SW	Y
Construction	Three-Piece Rod End with Zerk Fitting
Product Type	TR
Thread Type	UNF
Series	Precision
Outer Material	Carbon Steel - Corrosion Resistant Plating
Axial Load	1,130
Across Wrench Flats	1
Race Material	Carbon Steel - corrosion resistant plating
Product Selection Available SW	Y
Lubrication Type	Grease
Misalignment Angle - a Deg. +/-	7
Housing Style	Female Rod End
Bearing Type	Rod End
Thread	RH
Type	Female Rod End
Lubrication	Zerk Fitting
Max Static Radial Load	11,300
Class	Precision
Bore Size (in)	0.7500 in
Lubrication Method	Fitting
Ability to Relubricate	Yes
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288719908
Weight	0.68 LB
Packaged Length	4.95 IN
Packaged Width	2.60 IN
Packaged Height	1.35 IN
HTC	8483.30.8055
Country of Origin	Mexico
