• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Thread Length (in)	1.719 in
Thread Size	#3/4-16
Housing Width (in)	0.687 in
Ball Width (in)	0.875 in
Base Diameter (in)	1.125 in
Ball Diameter (in)	1.312 in
Ball Flat Diameter (in)	0.978 in
Head Diameter (in)	1.75 in
Length to Center of Ball (in)	2.88 in

Technical Specifications

Construction	Three-Piece Rod End with Zerk Fitting
Outer Material	Carbon Steel - Corrosion Resistant Plating
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Product Selection Available SW	Y
Bearing Type	Rod End
Configuration	Female
Misalignment Angle - a Deg. +/-	7
Housing Style	Female Rod End
Series	Precision
Race Material	Carbon Steel - corrosion resistant plating
Zerk Fitting SW	N
Axial Load	1,130
Across Wrench Flats	1
Lubrication Type	Grease
Thread Type	UNF
Product Type	TR
Thread	RH
Lubrication	No Zerk Fitting
Type	Female Rod End
Max Static Radial Load	11,300
Bore Size (in)	0.7500 in
Class	Precision
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288719144
Weight	0.68 LB
Packaged Length	4.20 IN
Packaged Width	2.55 IN
Packaged Height	1.70 IN
HTC	8483.30.8055
Country of Origin	Mexico
