• Three-piece precision construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• One-Piece Carbon Steel Outer Race

Dimensions

Housing Width (in)	0.562 in
Ball Flat Diameter (in)	0.839 in
Ball Diameter (in)	1.125 in
Thread Length (in)	1.469 in
Base Diameter (in)	1 in
Ball Width (in)	0.75 in
Head Diameter (in)	1.5 in
Thread Size	#5/8-18
Length to Center of Ball (in)	2.5 in

Technical Specifications

Misalignment Angle - a Deg. +/-	8
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Lubrication Type	Grease
Bearing Type	Rod End
Zerk Fitting SW	N
Series	Precision
Axial Load	805
Product Selection Available SW	Y
Housing Style	Female Rod End
Race Material	Carbon Steel - corrosion resistant plating
Outer Material	Carbon Steel - Corrosion Resistant Plating
Across Wrench Flats	0.875
Configuration	Female
Construction	Three-Piece Rod End with Zerk Fitting
Product Type	TR
Thread Type	UNF
Type	Female Rod End
Thread	RH
Max Static Radial Load	8,050
Lubrication	No Zerk Fitting
Bore Size (in)	0.6250 in
Class	Precision
Lubrication Method	No Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	None

General Specifications

UPC	662288719137
Weight	0.46 LB
Packaged Length	3.85 IN
Packaged Width	2.45 IN
Packaged Height	1.40 IN
HTC	8483.30.8055
Country of Origin	Mexico
