• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Left-Hand Threads

Dimensions

Housing Width (in)	0.562 in
Head Diameter (in)	1.5 in
Ball Diameter (in)	1.125 in
Thread Size	#5/8-18
Ball Flat Diameter (in)	0.839 in
Thread Length (in)	1.594 in
Ball Width (in)	0.75 in
Length to Center of Ball (in)	2.63 in

Technical Specifications

Configuration	Male
Race Material	Bronze
Product Selection Available SW	Y
Thread Type	UNF
Misalignment Angle - a Deg. +/-	8
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Axial Load	805
Series	Commercial
Outer Material	Carbon Steel - Corrosion Resistant Plating
Lubrication Type	Grease
Housing Style	Male Rod End
Construction	Three-Piece Rod End with Zerk Fitting
Bearing Type	Rod End
Zerk Fitting SW	Y
Product Type	TM
Thread	LH
Type	Male Rod End
Max Static Radial Load	8,050
Lubrication	Zerk Fitting
Class	Commercial
Bore Size (in)	0.6250 in
Lubrication Method	Fitting
Ability to Relubricate	Yes
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288724285
Weight	0.42 LB
Packaged Length	5.10 IN
Packaged Width	5.10 IN
Packaged Height	2.70 IN
HTC	8483.30.8055
Country of Origin	Mexico
