• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads
• Y Stud

Dimensions

Ball Flat Diameter (in)	0.698 in
Housing Width (in)	0.5 in
Ball Width (in)	0.625 in
Head Diameter (in)	1.312 in
Thread Size	#1/2-20
Ball Diameter (in)	0.937 in
Thread Length (in)	1.469 in
Length to Center of Ball (in)	2.44 in
Stud Thread Length (in)	1 in
Stud Length to Center of Ball (in)	2 in
Stud Length to Hex (in)	1.13 in

Technical Specifications

Bearing Type	Rod End
Axial Load	700
Outer Material	Carbon Steel - Corrosion Resistant Plating
Zerk Fitting SW	Y
Construction	Three-Piece Rod End with Y Stud and Zerk Fitting
Configuration	Male
Y Stud Material	Carbon Steel - corrosion resistant plating
Housing Style	Male Rod End
Product Type	TM
Series	Commercial
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Thread Type	UNF
Product Selection Available SW	N
Race Material	Bronze
Lubrication Type	Grease
Thread	RH
Type	Male Rod End
Max Static Radial Load	7,000
Lubrication	Zerk Fitting
Misalignment Angle B3	24.3
Class	Commercial
Bore Size (in)	0.5000 in
Lubrication Method	Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	Yes

General Specifications

UPC	662288724476
Weight	0.40 LB
Packaged Length	3.09 IN
Packaged Width	2.31 IN
Packaged Height	1.31 IN
HTC	8483.30.8055
Country of Origin	Mexico
