• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads

Dimensions

Head Diameter (in)	1.312 in
Ball Diameter (in)	0.937 in
Housing Width (in)	0.5 in
Ball Flat Diameter (in)	0.698 in
Thread Size	#1/2-20
Ball Width (in)	0.625 in
Thread Length (in)	1.469 in
Length to Center of Ball (in)	2.44 in

Technical Specifications

Axial Load	700
Housing Style	Male Rod End
Lubrication Type	Grease
Zerk Fitting SW	Y
Race Material	Bronze
Misalignment Angle - a Deg. +/-	6
Construction	Three-Piece Rod End with Zerk Fitting
Product Selection Available SW	Y
Thread Type	UNF
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Bearing Type	Rod End
Configuration	Male
Series	Commercial
Product Type	TM
Outer Material	Carbon Steel - Corrosion Resistant Plating
Lubrication	Zerk Fitting
Thread	RH
Max Static Radial Load	7,000
Type	Male Rod End
Bore Size (in)	0.5000 in
Class	Commercial
Lubrication Method	Fitting
Ability to Relubricate	Yes
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288724179
Weight	0.27 LB
Packaged Length	3.90 IN
Packaged Width	1.31 IN
Packaged Height	0.63 IN
HTC	8483.30.8055
Country of Origin	Mexico
