• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads

Dimensions

Ball Width (in)	0.625 in
Thread Length (in)	1.469 in
Ball Diameter (in)	0.937 in
Ball Flat Diameter (in)	0.698 in
Head Diameter (in)	1.312 in
Housing Width (in)	0.5 in
Thread Size	#1/2-20
Length to Center of Ball (in)	2.44 in

Technical Specifications

Bearing Type	Rod End
Zerk Fitting SW	N
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Race Material	Bronze
Housing Style	Male Rod End
Product Type	TM
Misalignment Angle - a Deg. +/-	6
Series	Commercial
Lubrication Type	Grease
Configuration	Male
Thread Type	UNF
Outer Material	Carbon Steel - Corrosion Resistant Plating
Axial Load	700
Construction	Three-Piece Rod End
Product Selection Available SW	Y
Lubrication	No Zerk Fitting
Max Static Radial Load	7,000
Type	Male Rod End
Thread	RH
Class	Commercial
Bore Size (in)	0.5000 in
Lubrication Method	No Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	None

General Specifications

UPC	662288718741
Weight	0.28 LB
Packaged Length	4.30 IN
Packaged Width	4.00 IN
Packaged Height	2.60 IN
HTC	8483.30.8055
Country of Origin	Mexico
