• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads

Dimensions

Ball Width (in)	0.5 in
Thread Length (in)	1.219 in
Thread Size	#3/8-24
Housing Width (in)	0.406 in
Head Diameter (in)	1 in
Ball Diameter (in)	0.718 in
Ball Flat Diameter (in)	0.517 in
Length to Center of Ball (in)	1.94 in

Technical Specifications

Lubrication Type	Grease
Race Material	Bronze
Axial Load	400
Series	Commercial
Configuration	Male
Product Selection Available SW	Y
Zerk Fitting SW	Y
Outer Material	Carbon Steel - Corrosion Resistant Plating
Bearing Type	Rod End
Thread Type	UNF
Misalignment Angle - a Deg. +/-	6
Product Type	TM
Housing Style	Male Rod End
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Construction	Three-Piece Rod End with Zerk Fitting
Type	Male Rod End
Max Static Radial Load	4,000
Thread	RH
Lubrication	Zerk Fitting
Class	Commercial
Bore Size (in)	0.3750 in
Lubrication Method	Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	Yes

General Specifications

UPC	662288724155
Weight	0.13 LB
Packaged Length	2.40 IN
Packaged Width	2.35 IN
Packaged Height	0.55 IN
HTC	8483.30.8055
Country of Origin	Mexico
