• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads

Dimensions

Thread Size	#5/16-24
Thread Length (in)	1.219 in
Housing Width (in)	0.344 in
Head Diameter (in)	0.875 in
Ball Diameter (in)	0.625 in
Ball Flat Diameter (in)	0.447 in
Ball Width (in)	0.437 in
Length to Center of Ball (in)	1.88 in

Technical Specifications

Configuration	Male
Zerk Fitting SW	Y
Housing Style	Male Rod End
Misalignment Angle - a Deg. +/-	7
Series	Commercial
Bearing Type	Rod End
Race Material	Bronze
Product Selection Available SW	Y
Product Type	TM
Construction	Three-Piece Rod End with Zerk Fitting
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Outer Material	Carbon Steel - Corrosion Resistant Plating
Axial Load	250
Thread Type	UNF
Lubrication Type	Grease
Type	Male Rod End
Thread	RH
Lubrication	Zerk Fitting
Max Static Radial Load	2,500
Class	Commercial
Bore Size (in)	0.3125 in
Lubrication Method	Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	Yes

General Specifications

UPC	662288726586
Weight	0.50 LB
Packaged Length	5.15 IN
Packaged Width	2.20 IN
Packaged Height	0.65 IN
HTC	8483.30.8055
Country of Origin	Mexico
