• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads

Dimensions

Ball Flat Diameter (in)	0.447 in
Ball Width (in)	0.437 in
Ball Diameter (in)	0.625 in
Thread Size	#5/16-24
Thread Length (in)	1.219 in
Housing Width (in)	0.344 in
Head Diameter (in)	0.875 in
Length to Center of Ball (in)	1.88 in

Technical Specifications

Lubrication Type	Grease
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Construction	Three-Piece Rod End
Thread Type	UNF
Zerk Fitting SW	N
Axial Load	250
Housing Style	Male Rod End
Series	Commercial
Misalignment Angle - a Deg. +/-	7
Configuration	Male
Product Selection Available SW	Y
Bearing Type	Rod End
Product Type	TM
Outer Material	Carbon Steel - Corrosion Resistant Plating
Race Material	Bronze
Max Static Radial Load	2,500
Thread	RH
Type	Male Rod End
Lubrication	No Zerk Fitting
Class	Commercial
Bore Size (in)	0.3125 in
Lubrication Method	No Fitting
Ability to Relubricate	None
Maximum Ambient Temperature (F)	350 °F

General Specifications

UPC	662288723561
Weight	0.08 LB
Packaged Length	2.50 IN
Packaged Width	2.25 IN
Packaged Height	1.40 IN
HTC	8483.30.8055
Country of Origin	Mexico
