• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads

Dimensions

Ball Width (in)	0.375 in
Ball Flat Diameter (in)	0.331 in
Housing Width (in)	0.281 in
Thread Size	#1/4-28
Thread Length (in)	0.969 in
Ball Diameter (in)	0.5 in
Head Diameter (in)	0.75 in
Length to Center of Ball (in)	1.56 in

Technical Specifications

Outer Material	Carbon Steel - Corrosion Resistant Plating
Series	Commercial
Housing Style	Male Rod End
Configuration	Male
Bearing Type	Rod End
Lubrication Type	Grease
Thread Type	UNF
Construction	Three-Piece Rod End
Product Type	TM
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Axial Load	170
Zerk Fitting SW	N
Misalignment Angle - a Deg. +/-	8
Product Selection Available SW	Y
Race Material	Bronze
Type	Male Rod End
Max Static Radial Load	1,700
Lubrication	No Zerk Fitting
Thread	RH
Bore Size (in)	0.2500 in
Class	Commercial
Lubrication Method	No Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	None

General Specifications

UPC	662288723554
Weight	0.47 LB
Packaged Length	2.25 IN
Packaged Width	2.20 IN
Packaged Height	0.60 IN
HTC	8483.30.8055
Country of Origin	Mexico
