• Two-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Male External Threads

Dimensions

Thread Size	#5/8-18
Ball Width (in)	0.75 in
Head Diameter (in)	1.5 in
Thread Length (in)	1.594 in
Housing Width (in)	0.562 in
Ball Diameter (in)	1.125 in
Ball Flat Diameter (in)	0.839 in
Length to Center of Ball (in)	2.63 in

Technical Specifications

Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Housing Style	Male Rod End
Bearing Type	Rod End
Lubrication Type	Grease
Race Material	Bronze
Outer Material	Carbon Steel - Corrosion Resistant Plating
Zerk Fitting SW	N
Misalignment Angle - a Deg. +/-	8
Axial Load	805
Construction	Three-Piece Rod End
Configuration	Male
Product Selection Available SW	Y
Series	Commercial
Thread Type	UNF
Product Type	TM
Type	Male Rod End
Max Static Radial Load	8,050
Thread	RH
Lubrication	No Zerk Fitting
Bore Size (in)	0.6250 in
Class	Commercial
Lubrication Method	No Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	None

General Specifications

UPC	662288723592
Weight	0.41 LB
Packaged Length	2.15 IN
Packaged Width	4.30 IN
Packaged Height	0.85 IN
HTC	8483.30.8055
Country of Origin	Mexico
