• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• Powder coat epoxy cast iron housing
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• USDA H1 complaint food grade grease
• Exclusive locking pin and dimple system provides a direct lubricant into the bearing cavity and ball path instead of around a lubrication groove, prevents outer ring rotation.
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.

Dimensions

Bolt Size (in)	3/8 in
Overall Width (in)	2.75 in
Overall Length (in)	3.75 in
Overall Height (in)	1.438 in
Bore Diameter (in)	1 in
Foot Height (in)	0.69 in
Length Through Bore (in)	1.375 in
Bolt Spacing (in)	3.0000 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Options	Corrosion Resistant
Certifications	IP69K
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Multi-Lip Contact Seal
Housing Type	Flange, Two Bolt
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Setscrew Torque (in-lbs)	45 in/lbs
Radial Clearance	Standard
Vibration Frequency Fundamental Train	0.0068 cps
Dynamic Load Rating (lb)	2,801 lb
Vibration Frequency Inner Ring Defect	0.0985 cps
Bearing Type	Standard Duty
Bearing Insert Finish	Phosphorus Nickel Coated
Vibration Frequency Roller Spin	0.0442 cps
Housing Material	Cast Iron
Size Code	2-015
Vibration Frequency Outer Ring Defect	0.0682 cps
Max Operating Temperature (F)	220 °F
Fixed vs. Expansion	Fixed
Lubricant	Lithium Complex NLGI 2 Grease
Inner Ring Outside Diameter (in)	1.375 in
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Insert Material	52100 Bearing Steel
Grease Fitting Thread Size	1/4-28
Shaft Locking Type	Concentric
Insert	PN-16
Cage Type	Land Riding Retainer
Static Load Rating (lb)	1,651 lb
Maximum Speed (RPM)	2700 rpm
Housing Coating	Powder Coated
End Cap Available	No

General Specifications

UPC	662461372166
Weight	1.40 LB
Packaged Length	4.00 IN
Packaged Width	1.50 IN
Packaged Height	3.94 IN
HTC	8483.20.4040
Country of Origin	United States of America
