• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew with diamond faceted setscrews
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	3/8 in
Overall Width (in)	2.75 in
Overall Height (in)	1.438 in
Overall Length (in)	3.75 in
Bore Diameter (in)	0.9375 in
Foot Height (in)	0.69 in
Length Through Bore (in)	1.375 in
Bolt Spacing (in)	3.0000 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Black
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Felt Labyrinth Seal
Housing Type	Flange, Two Bolt
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Setscrew Torque (in-lbs)	85 in/lbs
Bearing Insert Finish	Black Oxide
Vibration Frequency Inner Ring Defect	0.0985 cps
Inner Ring Outside Diameter (in)	1.375 in
Size Code	2-015
Insert	2-15C
Maximum Speed (RPM)	6350 rpm
Grease Fitting Thread Size	1/4-28
Cage Type	Land Riding Retainer
Shaft Locking Type	Set Screw
Vibration Frequency Fundamental Train	0.0068 cps
Max Operating Temperature (F)	220 °F
Housing Material	Cast Iron
End Cap Available	No
Bearing Insert Material	52100 Bearing Steel
Dynamic Load Rating (lb)	2,801 lb
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Type	Standard Duty
Vibration Frequency Outer Ring Defect	0.0682 cps
Static Load Rating (lb)	1,651 lb
Vibration Frequency Roller Spin	0.0442 cps
Lubricant	Lithium Complex NLGI 2 Grease
Radial Clearance	Standard
Fixed vs. Expansion	Fixed
Housing Coating	Powder Coated

General Specifications

UPC	662461141281
Weight	1.25 LB
Packaged Length	4.00 IN
Packaged Width	1.50 IN
Packaged Height	3.94 IN
HTC	8483.20.4040
Country of Origin	United States of America
