• Three-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Left-Hand Threads
• One-Piece Bronze Race

Dimensions

Thread Length (in)	0.906 in
Ball Width (in)	0.5 in
Ball Diameter (in)	0.718 in
Thread Size	#3/8-24
Ball Flat Diameter (in)	0.517 in
Head Diameter (in)	1 in
Base Diameter (in)	0.688 in
Housing Width (in)	0.406 in
Length to Center of Ball (in)	1.63 in

Technical Specifications

Across Wrench Flats	0.562
Product Type	TF
Construction	Three-Piece Rod End
Lubrication Type	Grease
Series	Commercial
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Race Material	Bronze
Misalignment Angle - a Deg. +/-	6
Thread Type	UNF
Bearing Type	Rod End
Configuration	Female
Product Selection Available SW	Y
Axial Load	445
Housing Style	Female Rod End
Zerk Fitting SW	N
Outer Material	Carbon Steel - Corrosion Resistant Plating
Max Static Radial Load	4,450
Thread	LH
Type	Female Rod End
Lubrication	No Zerk Fitting
Class	Commercial
Bore Size (in)	0.3750 in
Lubrication Method	No Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	None

General Specifications

UPC	662288723646
Weight	0.14 LB
Packaged Length	5.20 IN
Packaged Width	1.80 IN
Packaged Height	0.65 IN
HTC	8483.30.8055
Country of Origin	Mexico
