• Three-Piece Commercial Construction
• Heat Treated, Chrome Plated Ball
• Heat Treated, Plated Alloy steel housing
• Female External Threads
• One-Piece Bronze Race

Dimensions

Thread Size	#5/16-24
Ball Diameter (in)	0.625 in
Thread Length (in)	0.719 in
Head Diameter (in)	0.875 in
Ball Flat Diameter (in)	0.447 in
Ball Width (in)	0.437 in
Housing Width (in)	0.344 in
Base Diameter (in)	0.531 in
Length to Center of Ball (in)	1.38 in

Technical Specifications

Across Wrench Flats	0.437
Configuration	Female
Housing Style	Female Rod End
Series	Commercial
Race Material	Bronze
Ball Material	Alloy Steel - Heat Treated - Chrome Plated
Bearing Type	Rod End
Misalignment Angle - a Deg. +/-	7
Lubrication Type	Grease
Thread Type	UNF
Axial Load	335
Zerk Fitting SW	Y
Product Selection Available SW	Y
Outer Material	Carbon Steel - Corrosion Resistant Plating
Product Type	TF
Construction	Three-Piece Rod End with Zerk Fitting
Type	Female Rod End
Thread	RH
Lubrication	Zerk Fitting
Max Static Radial Load	3,350
Bore Size (in)	0.3125 in
Class	Commercial
Lubrication Method	Fitting
Maximum Ambient Temperature (F)	350 °F
Ability to Relubricate	Yes

General Specifications

UPC	662288726623
Weight	0.09 LB
Packaged Length	2.35 IN
Packaged Width	2.20 IN
Packaged Height	0.55 IN
HTC	8483.30.8055
Country of Origin	Mexico
