• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	1.437 in
Bore Size (in)	1.5000 in
Inner Ring OD (in)	2.06 in
Inner Race Length (in)	1.437 in
Centerline to Front Face (in)	0.717 in
Outer Race OD (in)	3.149 in
Outer Race Width (in)	1.188 in

Technical Specifications

Bore Shape	Straight
Insert Material	52100 Bearing Steel, Black Oxided
Rolling Element	Ball Bearing
Housing Type	Insert Only
Measure Units	Inch
Radius	0.04
Speed (Max) (RPM)	400 rpm
Misalignment	±2.0° Misalignment - Static Only
Internal Clearance	Standard
Radial Dynamic Load Capacity (lb)	7,340 lb
Outer Ring Land Profile	Standard
End Cap	No
Platform	Gold Line Ball Bearing
Misalignment Type	Static Only
Bearing Insert Coating	Black Oxide Coated
Radial Static Load Capacity (lb)	4,467 lb
Precision Rating	ABEC 1
Series	TCS
Cage Material	Molded Nylon
Outer Race Profile	Cylindrical
Inner Race Profile	Wide Inner Ring
Inner Race Heat Treat Method	Zone-Hardened
Retainer Type	Land Riding Retainer
Ability to Relubricate	Yes
Maximum Operating Temperature (F)	220 °F
Lubrication Type	Lithium Complex NLGI 2 Grease
Duty/Series	Standard
Locking Type	No Locking
Type of Seal	Triple Lip Contact Seal
Fixed vs. Expansion	No

General Specifications

UPC	662461009161
Weight	1.67 LB
Packaged Length	3.63 IN
Packaged Width	2.00 IN
Packaged Height	3.63 IN
HTC	8482.10.5052
Country of Origin	Mexico
